Gas infrared radiation heating has energy saving, environmental protection and comfort

time：2023-07-04
hits：999次
source：正弘奥能

Natural gas and liquefied natural gas are considered to be one of the clean energy sources in the world, and gas infrared radiation heating equipment uses natural gas and liquefied natural gas as fuel, so it fully meets the requirements of national environmental protection.Since the gas infrared radiation heating equipment heats objects and Spaces through infrared radiation in operation, there is no noise and no ash phenomenon, which is the real heating in the heating products.In addition, the main components of natural gas combustion are carbon dioxide and water vapor, so it can effectively reduce the dry problem of indoor heating in winter and improve the comfort of the human body.





	The use of natural gas, liquefied petroleum gas and other fuels, burning in a special combustion device - radiation tube and radiation of various wavelengths of infrared radiation for heating, infrared is a part of the entire electromagnetic wave band.Different wavelengths of electromagnetic waves, after contact with the object, will produce different effects.The electromagnetic wave with a wavelength between 0.76 and 1000 microns, especially the electromagnetic wave with a wavelength between 0.76 and 40 microns, has non-dispersion, therefore, the energy is concentrated and the thermal effect is significant, so it is called heat rays or infrared rays.The infrared wavelength emitted by the gas radiation tube is exactly in this range.Since radiant heat is not absorbed by the atmosphere, it is absorbed by various objects such as buildings, human bodies, equipment, and so on, and is converted into heat energy.The body that absorbs the heat rises in temperature, and again heats other objects around it, such as the atmosphere, in the form of convection.Therefore, the atmospheric temperature in tall space buildings will not produce serious vertical imbalance.Therefore, it has a high utilization rate of heat energy and makes the human body feel very comfortable.Therefore, gas infrared radiation heating is an ideal heating method for tall Spaces such as industrial plants.





	<img src="http://www.leadwaypower.com/Uploads/image/20230704/20230704113638_93023.jpg" alt="" />





	Main features of infrared radiant heating system


	(1) The heat generator is installed outdoors, and the radiation tube is installed in the upper part of the room, which does not occupy the building area.


	(2) The indoor temperature distribution along the height direction is uniform, the vertical temperature gradient is small, and the ineffective heat loss is greatly reduced.


	(3) It improves the surface temperature of the interior and exterior walls, reduces the cold radiation of the surface of the enclosure structure to the human body, and improves the comfort.


	(4) No air disturbance, thus reducing the possibility of dust flying, which is conducive to improving health conditions.





	Gas infrared radiation heating is not suitable for buildings with small areas and small Spaces.It can be used for comprehensive heating of buildings with a height of 3m~30m and local area or local workplace heating, and its use is very wide, including large shipyards, ships, aircraft and automobile maintenance halls and other high space occasions.Because the gas infrared radiation heating is imported, the initial investment is relatively high, but under the premise of establishing the same comfortable conditions, the design temperature of the gas infrared radiation heating room can be reduced by 2 to 3° than that of the convection heating, which can save heating energy consumption and save a lot of operating costs, so the gas infrared radiation heating is still the first choice for tall space heating.





	IMPRESIND gas radiant heating system, as the main heating equipment of Beijing Leadway Power&nbsp;Co., LTD., has become one of the leading products in the Chinese market after more than 10 years of promotion and application.IMPRESIND gas radiant heating system saves the huge and complex boiler and boiler room equipment, short installation cycle, does not occupy the building's use area, the radiation tube is generally installed in the upper part of the building heating space, so it rarely occupies or does not occupy the building's use area, saving valuable building land.There is no loss of gas in the transmission process, and the combustion of the generator is very complete, so the heat of the entire heating system can be fully utilized.
