Energy saving heating solution for industrial plants in high space - IMPRESIND Gas radiant heating system

time：2024-08-02
hits：345次
source：正弘奥能

In the tall space building, the choice of winter heating method is very important. How to realize energy saving and not pollute the environment has also become one of the core issues that enterprises focus on. At present, many enterprises are still using traditional convection heating methods. The traditional convection heating method, due to the rise of hot air, makes a large amount of heat consumed in the upper part of the tall space building, the lower working area is difficult to obtain enough heat, and the temperature distribution is uneven, which not only causes the waste of energy, but also the thermal comfort is poor, has been proved to be a heating method not suitable for tall space buildings. At present, according to the different nature of the use of tall space buildings, the heating of tall space can choose to use radiation heating.





	<img src="http://www.leadwaypower.com/Uploads/image/20240802/20240802103353_65340.jpg" alt="" />


In the case of radiation heating, the heat loss of tall space buildings is lower than that of convective heating, which is mainly due to several reasons:

(1) Since radiant heating directly irradiates the heating object and hardly heats the air in the environment, the air temperature of radiant heating is lower than that of convective heating under the same health conditions, and can generally be lower by 2-5, so the temperature difference between indoor and outdoor is small, so the cold air permeability is also small.

(2) Due to convective heating, indoor air is heated, and the convection of hot and cold air is formed, so the indoor air temperature has a large gradient, the roof part of the temperature is high, the temperature near the ground is low, the general convective heating temperature gradient is about 0.5-1.0/ m, and radiant heating, radiant heat directly radiates downward, the ground part can also save some heat. Therefore, the indoor air temperature gradient is small, and the corresponding heat loss in the upper part of the building is also small.

(3) The heat of the gas heating system can be fully utilized, while the traditional radiator heating system, after the heat source is drawn from the boiler, there is a heat loss of 10-15% along the way, so the thermal efficiency is low.


	In the radiation heating method, gas radiation heating radiation heating system with gas as energy saving energy can reach 30-50%, which can greatly reduce operating costs. The gas radiation heating system runs quietly, does not produce convective air, avoids the ash phenomenon in the industrial plant, and can improve the health conditions of the heating space. The indoor heating speed is fast, the heat distribution is uniform, and the body feeling is comfortable and soft.





	<img src="http://www.leadwaypower.com/Uploads/image/20240802/20240802103406_67540.jpg" alt="" />


IMPRESIND gas radiant heating system, promoted and sold by Beijing Leadway Power Co., LTD., has become one of the leading products in the Chinese market through more than 10 years of promotion and application. IMPRESIND gas radiant heating system installation period is short, does not occupy the use of the building area. The combustion of the generator is very complete, the heat conversion efficiency is more than 95%, and the heat of the entire heating system is fully utilized. There is no strong convection phenomenon, indoor air stratification is weak, thermal inertia is small, temperature difference is small, reduce heat loss. In tall space industrial buildings, reducing vertical gradient heat loss means saving energy and economic costs, which can reduce energy consumption by 30% to 60%.

Using IMPRESIND gas radiation heating system, there is no need to install a large and complex boiler room, heat exchange station and related heat pipelines, such as gas radiation heating system only needs to be connected with the gas pipe network, and the initial investment is greatly reduced. The system layout is simple, and the installation is suspended, which does not occupy the use area in the building and saves valuable building land. The system does not need to set up a special post to work or operate. Compared with traditional convective heating, the workload of operation, maintenance, overhaul and maintenance is greatly reduced, and the operation and maintenance cost is reduced.
