The modular installation of ECOPAN hot water radiant panel meets various engineering planning requirements

time：2024-05-21
hits：464次
source：正弘奥能

Our government has developed and implemented a range of clean energy policies and carbon emission targets to address challenges such as climate change and energy security. These policies put forward strict restrictions and regulations on traditional fossil energy use. Therefore, the heating equipment market is also changing to the direction of low carbon, efficient and environmental protection. At the same time, with people's demand for high space environment comfort and energy saving, radiation heating has become a comfortable and energy-saving heating technology worth promoting.





	<img src="http://www.leadwaypower.com/Uploads/image/20240521/20240521100327_67714.png" alt="" />


Among them, the hot water radiant panel heating system is energy efficient, static heating, convenient construction, durable, widely used is the ideal choice for industrial plants, hangars, warehousing, logistics, pavilions and gymnasiums and other tall space buildings heating. By Beijing Leadway Power Co., Ltd. sales and promotion of the ECOPAN hot water radiation plate is made of cold-formed pressed steel plate, on the shell of the steel plate, with a diameter of 1/2 "or 3/4" electric welding or non-welded steel pipe wrapped 2/3 of its surface, increasing the heat transfer area, excellent guarantee of heat transfer from the tube to the plate. Hot water radiant panel has long service life and low maintenance cost.

The ECOPAN hot water radiant panel has 22 modules to provide designers with a wider choice and to meet the needs of various engineering plans. The radiant panel is composed of 4 meters and/or 6 meters of modules, so the pipes connecting each module element by welding or crimping can obtain different lengths, achieving fast connection, which can shorten the construction period and save labor costs to a certain extent.


	In order to do this without damaging the painted board, the pipes on both sides are longer than the board itself. When the pipe connection is complete, a decorative cover plate is inserted between the plates to cover the connection area and make the product look more beautiful. The decorative cover plate is fixed with a fixing card, which saves installation time and makes the installation work more time-saving and efficient. The decorative cover plate has the same profile as the motherboard, and laboratory tests confirm that the thermal energy efficiency of the decorative cover plate is exactly the same as that of the radiant panel.





	<img src="http://www.leadwaypower.com/Uploads/image/20240521/20240521100344_73905.png" alt="" />


The thermal insulation material covering the upper surface of the ECOPAN hot water radiant panel is thermal insulation cotton and the top is covered with aluminum foil. Based on a number of practical case studies, the selection of a rectangular section of the suspension bracket, this solution can quickly and evenly place the insulation pad, so that the glass wool perfectly adhered to the metal plate. This adhesion is even improved by using a fastening rod at the top. In order to contain the sides and hide the thermal insulation cotton, the side edges of the ECOPAN hot water radiant panel are obtained from the same radiant panel. They also enable faster and more precise laying of thermal insulation cotton.

With the same dimensional characteristics (pipe diameter, number and spacing, panel width), ECOPAN hot water radiant panels have a higher thermal output than other products on the market. This allows fewer quantities to be used to meet the same required output, saving on material and installation costs. Beijing Leadway Power&nbsp;Co., Ltd. can provide customers with the best installation solutions, optimize the construction time, thereby reducing the construction cost.
