ECOPAN hot water radiant panel can meet the heating needs of all kinds of large space

time：2024-02-20
hits：602次
source：正弘奥能

At present, the layout of tall space heating pipeline equipment is difficult. Because of the large heating load in the tall space, it is difficult to arrange the radiator when the radiator is used for heating. When floor heating is used, special treatment should be given to foundation heat insulation, ground heat dissipation and load. When using vertical air supply, horizontal air supply and gas radiant heating, it is also necessary to install pipelines and equipment safely and reliably. In response to these problems, hot water radiant panel heating can meet the various needs of tall space heating.


	The so-called radiation heating technology is a technology that uses the principle of infrared heating objects to heat human settlements. The heating equipment that works on the principle of thermal radiation is the radiation source, which is generally installed on the top of the building. People can move without any obstacles, and the use of floors and walls is not restricted. Hot water radiant panels can use hot water, superhot water, steam or diathermy oil as a heating fluid with a temperature range between 50 and 180°C. Thermal inertia is very low, hot water radiation panel is particularly suitable for industrial halls, offices, stadiums, stores, supermarkets and other tall space heating.





	<img src="http://www.leadwaypower.com/Uploads/image/20240220/20240220153903_75430.png" alt="" />


	<img src="http://www.leadwaypower.com/Uploads/image/20240220/20240220153913_14008.png" alt="" />


ECOPAN hot water radiant panel promoted and sold by Beijing Leadway Power Co., Ltd. can provide the best heating solution, which can not only make the construction operation easier, but also optimize the time, thereby reducing the cost. The side is formed in the radiant panel, easy to place the insulation material, the head of the pipe lining is welded perfectly, and the joint cover is easy to position, so that the installation time is shortened. ECOPAN hot water radiant panel is made of metal tube sheet, which is prefabricated in the factory into a standard length of 3 meters, 6 meters (special requirements can be prefabricated 2 meters, 4 meters). Each radiant panel can be connected with a quick connector. Each radiant panel and collection pipe is prefabricated in the factory and tested for safety.

With the same dimensional characteristics (pipe diameter, number and spacing, panel width), ECOPAN hot water radiant panels have higher thermal energy efficiency than other products on the market. This makes it possible to use fewer products to meet the same heating requirements, saving on materials and installation costs. No other heating system currently offers the same comfort at such a low administrative cost as the good radiant system of ECOPAN Hot Water radiant Panel. If designed and installed properly, the investment is one of the smallest on the market. Given that there is no maintenance required and the system remains unchanged over a period of time, it is easy to understand that this is the cheapest solution for heating large volumes.
