The application advantages of ECOPAN hot water radiant panel in large-space heating

time：2024-01-24
hits：647次
source：正弘奥能

In the cold areas of the north, winter heating is very important, especially in tall office areas or industrial workshops, only traditional convection heating methods such as heating can not provide enough heat to ensure the indoor temperature. With the rapid development of new technologies, new equipment and new energy, the emergence of new technologies and new products such as infrared radiation heating has provided new ideas for HVAC design for industrial heating. Compared with traditional heating methods, infrared radiation heating has the characteristics and advantages of fast thermal effect, uniform heating, high thermal efficiency, high efficiency and energy saving, green environmental protection, etc.


	The application of the suspended ceiling type hot water radiation panel greatly solves this problem, the heating route of the hot water radiation panel is the same as that of the heating system, which is the application of the boiler and the hot water pipe to form a loop to provide heat, and the difference is that the hot water radiation panel is suspended on the roof, which greatly saves the usable space. Moreover, the hot water radiant panel has the excellent characteristics of uniform heating, rapid heating and high thermal efficiency utilization, and has been more and more applied to the workshop and office area of tall industrial buildings.





	<img src="http://www.leadwaypower.com/Uploads/image/20240124/20240124101819_88502.jpg" alt="" />


On the basis of the improvement of heating safety, heating quality, energy saving and emission reduction technologies year by year, as a leader in environmental protection technology and services, Beijing Leadway Power&nbsp;Co., Ltd. has been taking infrared radiation heating technology as the core, actively grasping market demand, exploring comfortable industrial heating heat experience, and helping industrial enterprises to achieve energy saving and consumption reduction, intelligent heating development goals.


	ECOPAN hot water radiation board promoted and sold by Beijing Leadway Power Co., Ltd. adopts an innovative design concept, the main features of ECOPAN are: The radiation board is made of cold-formed pressed steel plate, on the shell of the steel plate, with a diameter of 1/2 "or 3/4" electric welded or non-welded steel pipe wrapped 2/3 of its surface. Paint with polyethylene-based powder, with special attention to expansion between pipe and plate, and technical solutions that make installation easier. As the warmest part of the panel, the pipe is completely downward, and 70% of its surface is wrapped by the metal plate (the wrapping Angle is more than 280°), which increases the heat transfer area, and perfectly ensures the transfer of heat from the tube to the plate, reducing the convective flow and increasing the radiation.





	<img src="http://www.leadwaypower.com/Uploads/image/20240124/20240124101830_92685.jpg" alt="" />


ECOPAN hot water radiant panel, because it is based on the principle of natural solar radiation, is the most effective heating system, high heat exchange efficiency, small temperature gradient, uniform heat and cold, energy saving 30%~50% than conventional floor heating and convective heating. In addition, due to the low thermal inertia of the ceiling radiant panels, the heating system can only be operated intermittently when necessary, and no other heating system can provide the same comfort at such a low administrative cost.

ECOPAN develops optimal production solutions that make operations on the construction site easier, optimize time, and thus reduce costs. The side is formed in the board, easy to place the insulation material, the head of the pipe lining is welded perfectly, and the joint cover is easy to position, so that the installation time is shortened. With the same dimensional characteristics (pipe diameter, number and spacing, panel width), ECOPAN panels have a higher thermal output than other products on the market.
