Why is hot water radiant panel a good choice for heating in large-space buildings？

time：2023-09-01
hits：532次
source：正弘奥能

In tall space buildings, the choice of winter heating method is very important, mainly considering human comfort, energy saving and other factors.Traditional heating methods, such as radiators, consume a lot of heat in the upper part of tall buildings, and the lower working area is difficult to obtain enough heat, and the temperature distribution is uneven.This not only causes more energy consumption, but also poor comfort and has been proven unsuitable for tall building Spaces.





	In contrast, radiation heating is more suitable for tall space heating, because there is no convective gas generation, will not produce hot and cold phenomenon, causing less dust, better health conditions, to provide employees with a comfortable working environment.Radiant heating is 2-3℃ lower than the design temperature of the traditional heating system, the body feeling is still very comfortable, and the temperature of the whole workshop is heated evenly, providing a reliable working environment for the production of enterprises.





	In the radiation heating products, the hot water radiation panel is the metal radiation panel combined with the tube plate as the radiation source, with ordinary hot water and high temperature hot water as the medium, the radiation panel series-type banded arrangement, and the heating system installed in the form of ceiling, energy-saving and efficient, no power noise, no air convection, no wind and no dust, is a high-quality choice for tall space heating.It can be used in industrial workshops, warehouses, gymnasiums, garages, shops, hangars, aircraft maintenance warehouses, automobile exhibition halls, shipyards, offices and other occasions.





	<img src="http://www.leadwaypower.com/Uploads/image/20230901/20230901093113_49166.png" alt="" />






		High efficiency and energy saving


		In the radiant heating environment, because the indoor air temperature is 2-3k lower than the air temperature in the convective heating system environment, it can also achieve environmental comfort, so energy saving.





		Low operating cost


		As a terminal heat dissipation device, the hot water radiation panel of the suspended ceiling requires no electromechanical parts, consumes no electrical energy, and runs almost maintenance-free, saving operating costs.





		Short payback period


		The ceiling hot water radiant panel heating system is mainly manifested in high initial investment, but its energy saving is obvious after operation, and the higher investment part can be compensated by energy saving in a few years.





		Uniform temperature distribution


		In the ceiling hot water radiant panel heating environment, the heat distribution is uniform, the body feeling is comfortable and soft, and there will be no local temperature uneven phenomenon such as the wind system heating environment.





		Static heating


		The ceiling hot water radiant panel heating system has no electric transmission equipment and runs very quietly.No wind, no dust.





		Safe and reliable


		Hot water radiant panel heating system for the water system heating, low temperature and pressure, does not increase the fire rating of the building, can be used in volatile and flammable building environment, will not cause the risk of fire and explosion.



	ECOPAN hot water radiant panel promoted and sold by Beijing Leadway Power Co., Ltd. can provide the best heating solution, which can make the construction operation easier and shorten the installation time.With the same dimensional characteristics (pipe diameter, number and spacing, panel width), ECOPAN panels have higher thermal energy efficiency than other products on the market.This allows a smaller number of radiant panels to be used to meet the same thermal energy efficiency requirements, saving on materials and installation costs.





	<img src="http://www.leadwaypower.com/Uploads/image/20230901/20230901093046_29025.png" alt="" />





	To reduce this thermal shock, ECOPAN implemented a 2m long sheet metal module, so that the 4m module consists of 2 plates and the 6m module consists of 3 plates.When the 2 meter plates are placed side by side, an expansion joint is formed.The welding point exists in the middle of each 2m sheet, so the expansion on both sides is less than 1mm.This ensures that the radiant panel will not deform during this time.
